Arduino MKR WiFi 1010

Regular Price
Sale Price
Regular Price
Sold Out
Unit Price


The MKR WiFi 1010 is a great choice for any beginner, maker, or professional to get started with the Internet of Things (IoT). Using the popular Arm® Cortex®-M0 32-bit SAMD21 processor, it also features the ECC508 crypto-chip for security. The board is part of the MKR family, where you can choose from a large variety of shields to build projects out of the box with minimal effort!

Please read: operating voltage is 3.3V

The microcontroller on this board runs at 3.3V, which means that you must never apply more than 3.3V to its Digital and Analog pins. Care must be taken when connecting sensors and actuators to assure that this limit of 3.3V is never exceeded. Connecting higher voltage signals, like the 5V commonly used with the other Arduino boards, will damage the board.

Please read: black conductive foam

You should remove the black conductive foam from the board pins before usage. If you don't remove it, the board may behave erratically.


  • Name Arduino® MKR WiFi 1010
  • SKU ABX00023
  • Compatibility MKR
  • SAMD21 Cortex®-M0+ 32bit low power ARM MCU
  • Micro USB (USB-B)
  • Built-in LED Pin 6
  • Digital I/O Pins 8
  • Analog Input Pins 7 (ADC 8/10/12 bit)
  • Analog Output Pins 1 (DAC 10 bit)
  • PMW Pins 13 (0 - 8, 10, 12, A3, A4)
  • External interrupts 10 (0, 1, 4, 5, 6, 7, 8 ,9, A1, A2)
  • Bluetooth® Nina W102 uBlox module
  • Wi-Fi Nina W102 uBlox module
  • Secure element ATECC508A
  • UART Yes
  • I2C Yes
  • SPI Yes
  • I/O Voltage 3.3V
  • Input Voltage (nominal) 5-7V
  • DC Current per I/O pin 7 mA
  • Supported battery Li-Po Single Cell, 3.7V, 1024mAh Minimum
  • Battery connector JST PH
  • Processor 48 MHz
  • RTC 32.768 kHz
  • SAMD21G18A 256KB Flash, 32KB SRAM
  • Nina W102 uBlox module 448 KB ROM, 520KB SRAM, 2MB Flash
  • Weight 32 g
  • Width 25 mm
  • Length 61.5 mm


  • 1x Arduino MKR WiFi 1010
